Ships within 15 days
View
View
View
View
| Model No | STLQ020PUR |
| Mounting Type | Surface Mount |
| Type of Product | Voltage Regulator |
| Output Voltage | 0.8 to 4.5 V |
Model No |
STLQ020PUR |
Mounting Type |
Surface Mount |
Type of Product |
Voltage Regulator |
Output Voltage |
0.8 to 4.5 V |
Dimension |
2.1 x 2.1 x 0.9 mm |
Country of Origin |
Philippines |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
No. Of Output |
1 |
Maximum Output Current |
200 mA |
Package Type |
DFN |
Output Type |
Adjustable |
Pin Count |
6 |
Reference Voltage |
0.78 to 0.81 V |
Minimum Input Voltage |
2 V |
Maximum Input Voltage |
5.5 V |
Load Regulation |
0.005 %/mA |
Height |
0.9 mm |
Quiescent current |
150 µA |
Length |
2.1 mm |
Maximum Operating Temperature |
+125 °C |
Line Regulation |
0.05 %/V |
Width |
2.1 mm |
Minimum Operating Temperature |
-40 °C |
Accuracy |
±13% |
