Hikoki Voltage Unit -20 to 55 ° C, 80% RH or less (no condensation / chargeable temperature range is 5 to 35 °, LR8533

Name: Hikoki Voltage Unit -20 to 55 ° C, 80% RH or less (no condensation / chargeable temperature range is 5 to 35 °, LR8533
Brand: HiKOKI
SKU: TES.VOL.746079508
Price: 259599 INR
Availability: InStock

Visit the HiKOKI Store

EMI starts at ₹23065/month. No Cost EMI available.

Available offers

Get Flat 10% off on your First Orders above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 3% off on First Order above ₹3,000

View

Features

Type of Product	Voltage Unit
Model No	LR8533
Length (mm)	57
Country of Origin	Japan

More HiKOKI Voltage Tester products More Voltage Tester products

100% Original Products

Secure Payments

100% Buyer Protection

Top Brands

specifications

Type of Product	Voltage Unit
Model No	LR8533
Length (mm)	57
Country of Origin	Japan
Included Components	Z3230 wireless LAN adapter x 1, instruction manual x 1, Z1008AC adapter x 1, mounting plate x 1, M3 x 4 screws x 2 (for mounting plate)
Name of Manufacturer/Packer/Importer	HIOKI E.E. CORPORATION
Function	With auto connect function
Mass (g)	370
Monotaro ID	74037049
Import Country	Direct Import from Japan
Specifications	[Control communication means] Connect the Z3230 wireless LAN adapter (supplied) for wireless connection, encryption function: WPA-PSK / WPA2-PSK, TKIP / AES, available channels: 1 channel to 11 channels
RoHS Directive	Correspondence
Width (mm)	154
Dimension (WxDxH)	154x106x57 mm
Height (mm)	106
Input Method	Scan method all channel isolation by semiconductor relay
Sampling Speed	1ms
Input terminals	Equipped with M3 screw type terminal block (2 terminals per channel) and terminal block cover
Interface	Wireless LAN (IEEE802.11b / g / n)
Buffer Memory	4M word (volatile memory), data retention in case of communication error / retransmission in case of communication recovery
Operating Temperature / Humidity Range	-20 to 55 ° C, 80% RH or less (no condensation / chargeable temperature range is 5 to 35 ° C)
Vibration Resistance	JISD1601: 19955.3 (1), Type 1: Passenger car, Condition: Equivalent to Type A
LED	Wireless connection / measurement status / error status / AC adapter / external power supply drive / battery drive / charge status
Communication Distance	30 m (outlook)
Storage Temperature/Humidity Range	-20 to 60 ℃, 80% RH or less (no condensation)
Target of Measurement	Voltage
Compatible Models	LR8450-01 Memory High Logger (model with wireless LAN)
No. of Channels	Input 5ch (voltage only)
