Ships within 19 days
Model No
Input Voltage (V)
View
View
View
View
| Mass (g) | About 1200 |
| Frame Material | Aluminum Die Casting |
| Insulation Resistance | 100 or more (DC500V mega) power supply connections and non-charged metal parts |
| Shape | Round type |
Mass (g) |
About 1200 |
Frame Material |
Aluminum Die Casting |
Insulation Resistance |
100 or more (DC500V mega) power supply connections and non-charged metal parts |
Shape |
Round type |
Type |
Standard Type |
Input Voltage (V) |
AC230 |
Frequency (Hz) |
50/60 |
Monotaro ID |
37655807 |
Thickness (mm) |
55 |
Type of Product |
AC Axial Fan (Leaded Wire Type) |
Standard |
UL |
Model No |
R87T-A6A07H |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Maximum Airflow |
5/5.8(50/60 Hz) m³/min |
Storage Temperature |
-40 to +85°C (no freezing) |
Rated Current (A) |
50 Hz: 0.210, 60 Hz: 0.190 |
Rated Voltage (V) |
230 |
Operation Ambient Temperature (°C) |
-20 to +70 (no freezing) |
Rated Rotation Speed (min⁻¹ [rpm]) |
50 Hz: 2800, 60 Hz: 3250 |
Category |
AC Axial Fans |
