| Mass (g) | About 280 |
| Included Bearing | ball bearing |
| Rated Input (W) (50 / 60Hz) | 7/6 |
| Isolation Voltage | AC 2000 V (1 minute) Power supply connection part and non-charged metal part |
Mass (g) |
About 280 |
Included Bearing |
ball bearing |
Rated Input (W) (50 / 60Hz) |
7/6 |
Isolation Voltage |
AC 2000 V (1 minute) Power supply connection part and non-charged metal part |
Frame Material |
Aluminum die casting |
Terminal |
Outlet Terminals: Terminal Type |
Shape |
Square |
Type |
AC fan |
Input Voltage (V) |
AC115 |
Ambient Humidity to Use |
25 to 85%RH |
Frequency (Hz) |
50/60 |
Allowable Voltage Fluctuation |
85 to 110% of rated voltage |
Monotaro ID |
46584483 |
Sound Pressure Level (dB) |
26/29(50/60 Hz) |
Insulation Class |
IEC Class B (130°C), UL Class A (105°C), CSA Class A (105°C) |
Type of Product |
AC Axial Fan |
Standard |
UL/CSA |
Model No |
R87F-A3A85LP |
Import Country |
Direct Import from Japan |
Country of Origin |
China |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Maximum Airflow |
0.6/0.7 m³/min (50/60 Hz) |
Series |
R87F Series |
Storage Temperature |
-40 to +85 ℃ (no freezing) |
Rated Voltage (V) |
AC 115 |
Operation Ambient Temperature (°C) |
-30 to +70 (no freezing) |
Insulation Resistance (MOhm) |
100 or more (DC500 V mega) power supply connections and non-charged metal parts |
