| Terminal | Lead |
| Shape | Square |
| Maximum Static Pressure (Pa) | 42/58(50/60 Hz) |
| Type | High Speed |
Terminal |
Lead |
Shape |
Square |
Maximum Static Pressure (Pa) |
42/58(50/60 Hz) |
Type |
High Speed |
Monotaro ID |
50594260 |
Sound Pressure Level (dB) |
37/40(50/60 Hz) |
Type of Product |
AC Axial Fan |
Model No |
R87T-A1A85H |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Maximum Airflow |
0.8/0.9(50/60 Hz) m³/min |
Motor Type |
Single-Phase Shaded Coil Induction Motor (2 Poles, Open Type) |
Bearing Type |
Ball Bearing |
Voltage |
AC100 V |
Rated Voltage (V) |
AC100 |
Frame Thickness (mm) |
38 |
Size (mm) |
Φ80xt38 |
Rotational Speed (min⁻¹ [rpm]) |
High Speed |
Power Supply Voltage |
AC100 |
Frame |
Aluminum Die Casting |
Category |
AC Axial Fans |
Maximum Air Volume |
0.8/0.9 (m 3 /min) (50/60Hz) |
