| Mass (g) | About 300 |
| Rated Input (W) (50 / 60Hz) | 13/11 |
| Frame Material | Aluminum Die Casting |
| Terminal | Outlet Terminals: Terminal Type |
Mass (g) |
About 300 |
Rated Input (W) (50 / 60Hz) |
13/11 |
Frame Material |
Aluminum Die Casting |
Terminal |
Outlet Terminals: Terminal Type |
Insulation Resistance |
100 or more (DC500V mega) power supply connections and non-charged metal parts |
Shape |
Square |
Type |
Standard Type |
Input Voltage (V) |
AC115 |
Frequency (Hz) |
50/60 |
Monotaro ID |
37655651 |
Thickness (mm) |
Twenty Five |
Type of Product |
AC Axial Fan |
Standard |
UL/CSA |
Model No |
R87F-A3A93HP |
Import Country |
Direct Import from Japan |
Country of Origin |
China |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Maximum Airflow |
50Hz: 0.9 m, 3/min 60Hz: 1.0 m, 3/min |
Series |
R87F Series |
Storage Temperature |
-40 to +85°C (no freezing) |
Rated Current (A) |
50 Hz: 0.116, 60 Hz: 0.098 |
Noise Level (dB) |
50 Hz: 34, 60 Hz: 38 |
Rated Voltage (V) |
AC 115 |
Rated Rotation Speed (min⁻¹ [rpm]) |
50 Hz: 2550, 60 Hz: 3050 |
Category |
AC Axial Fans |
