| Frame Material | Aluminum die casting |
| Mounting Hole Spacing, Square (mm) | 180 |
| Shape | Square |
| Type | Fan single item |
Frame Material |
Aluminum die casting |
Mounting Hole Spacing, Square (mm) |
180 |
Shape |
Square |
Type |
Fan single item |
Frequency (Hz) |
50/60 |
Monotaro ID |
538133 |
Sound Pressure Level (dB) |
(200V)65/69(50/60Hz), (220V)71(60Hz), (230V)66/71(50/60Hz) |
Type of Product |
AC Axial Flow Fan |
Model No |
MRW18-DTA |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Maximum Airflow |
(200 V)11.2/13(50/60 Hz), (220 V)13(60 Hz), (230 V)11.2/13(50/60 Hz) |
Current (A) (50/60Hz) |
(200V)0.40/0.50(50/60Hz), (220V)0.55(60Hz), (230V)0.40/0.55(50/60Hz) |
Series |
MRW |
Mass (Kg) |
2.6 |
Rated Voltage (V) |
Single Phase 200 |
Connection Type |
Terminal block |
Operation Mode |
(Normal rotation) Contact OFF, (Alarm output) Contact ON |
Speed Type |
Standard speed |
Additional Functions |
Low rotation alarm + contact type |
Specifications |
With alarm |
Alarm Output |
Relay output |
Input (W) |
(200V)53/73(50/60Hz), (220V)78(60Hz), (230V)66/81(50/60Hz) |
Capacitor Capacitance (μF) |
4 |
