| Frame Material | Aluminum die casting |
| Mounting Hole Spacing, Square (mm) | 160 |
| Shape | Square |
| Maximum Static Pressure (Pa) | (200V)127/157(50/60Hz), (220V)157(60Hz), (230V)157(60Hz) |
Frame Material |
Aluminum die casting |
Mounting Hole Spacing, Square (mm) |
160 |
Shape |
Square |
Maximum Static Pressure (Pa) |
(200V)127/157(50/60Hz), (220V)157(60Hz), (230V)157(60Hz) |
Type |
Fan single item |
Frequency (Hz) |
50/60 |
Monotaro ID |
37730576 |
Sound Pressure Level (dB) |
(200V)49/52(50/60Hz), (220V)53(60Hz), (230V)53(60Hz) |
Type of Product |
AC Propeller Fan |
Model No |
MRS16-TTM |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Maximum Airflow |
(200 V)6.2/7.3(50/60 Hz), (220 V)7.3(60 Hz), (230 V)7.3(60 Hz) |
Current (A) (50/60Hz) |
(200V)0.19/0.17(50/60Hz), (220V)0.18(50/60Hz), (230V)0.18(50/60Hz) |
Series |
MRS |
Mass (Kg) |
1.35 |
Rated Voltage (V) |
Three-Phase 200, 220, 230 |
Connection Type |
Terminal block |
Operation Mode |
(Normal rotation) L level <Internal transistor ON>, (Alarm output) H level <Internal transistor OFF> |
Additional Functions |
Low rotation alarm + non-contact type |
Specifications |
With alarm |
Alarm Output |
Open collector output |
Input (W) |
(200V)33/37(50/60Hz), (220V)41(50/60Hz), (230V)43(50/60Hz) |
