| Frame Material | Aluminum die casting |
| Mounting Hole Spacing, Square (mm) | 92 |
| Shape | Square |
| Maximum Static Pressure (Pa) | (220V)44(50Hz), (230V)44/59(50/60Hz) |
Frame Material |
Aluminum die casting |
Mounting Hole Spacing, Square (mm) |
92 |
Shape |
Square |
Maximum Static Pressure (Pa) |
(220V)44(50Hz), (230V)44/59(50/60Hz) |
Type |
Fan single item |
Material (Fan Blade) |
Polycarbonate (flame retardant grade V-0) |
Monotaro ID |
538517 |
Sound Pressure Level (dB) |
(220V)35(50Hz), (230V)35/39(50/60Hz) |
Type of Product |
AC Propeller Fan |
Model No |
MU925S-51 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Maximum Airflow |
(220 V)0.95(50 Hz), (230 V)0.95/1.1(50/60 Hz) |
Current (A) (50/60Hz) |
(220V)0.06(50Hz), (230V)0.07/0.06(50/60Hz) |
Series |
MU |
Mass (Kg) |
0.27 |
Rated Voltage (V) |
Single Phase 220/230 |
Frame Thickness (mm) |
25 |
Rated Rotation Speed (min⁻¹ [rpm]) |
(220V)2600(50Hz), (230V)2600/3000(50/60Hz) |
Speed Type |
Standard speed |
Specifications |
No alarm |
Input (W) |
(220V)8.5(50Hz), (230V)10.5/8(50/60Hz) |
Input Method |
Terminal |
Relative Humidity |
0.95 |
