| Maximum Static Pressure (Pa) | (200V)74/103, (220V)-/106, (230V)78/106 |
| Monotaro ID | 37731513 |
| Type of Product | AC Cross Flow Fan |
| Model No | MF930B-DC |
Maximum Static Pressure (Pa) |
(200V)74/103, (220V)-/106, (230V)78/106 |
Monotaro ID |
37731513 |
Type of Product |
AC Cross Flow Fan |
Model No |
MF930B-DC |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Current (A) (50/60Hz) |
(200V)0.20/0.25, (220V)-/0.25, (230V).020/0.25 |
Material |
(Motor case) Aluminum die-cast, (Case) Steel plate, (Runner) Aluminum |
Bearing Type |
ball bearing |
Voltage |
Single Phase 200/220/230 V |
Noise Level (dB (A)) (50/60Hz) |
(200V)58/60, (220V)-/62, (230V)60/63 |
Specifications |
Built-in capacitor |
Power Supply |
AC |
Direction of Rotation |
(Runner) Clockwise as viewed from the motor side |
Length (mm) |
(Runner) 300 |
Protection Devices |
Built-in thermal protector |
Air Volume (m³/min) |
6.0 (single phase 200V/50Hz) |
Rotational Speed (50/60Hz) (RPM) |
(200V)2500/2700, (220V)-/2950, (230V)2700/3000 |
