| Frame Material | Aluminum die casting |
| Mounting Hole Spacing, Square (mm) | 160 |
| Shape | Square |
| Maximum Static Pressure (Pa) | (100V)127/157(50/60Hz), (110V)157(60Hz), (115V)157(60Hz) |
Frame Material |
Aluminum die casting |
Mounting Hole Spacing, Square (mm) |
160 |
Shape |
Square |
Maximum Static Pressure (Pa) |
(100V)127/157(50/60Hz), (110V)157(60Hz), (115V)157(60Hz) |
Type |
Fan single item |
Frequency (Hz) |
50/60 |
Monotaro ID |
37730524 |
Sound Pressure Level (dB) |
(100V)49/52(50/60Hz), (110V)53(60Hz), (115V)53(60Hz) |
Type of Product |
AC Propeller Fan |
Model No |
MRS16-BUL |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Maximum Airflow |
(100 V)6.2/7.3(50/60 Hz), (110 V)7.3(60 Hz), (115 V)7.3(60 Hz) |
Current (A) (50/60Hz) |
(100V)0.47/0.46(50/60Hz), (110V)0.48(60Hz), (115V)0.49(60Hz) |
Series |
MRS |
Mass (Kg) |
1.35 |
Rated Voltage (V) |
Single Phase 100, 110, 115 |
Connection Type |
Terminal block |
Additional Functions |
None |
Specifications |
No alarm |
Input (W) |
(100V)39/41(50/60Hz), (110V)48(60Hz), (115V)51(60Hz) |
Capacitor Capacitance (μF) |
3 |
