| Frame Material | Aluminum die casting |
| Mounting Hole Spacing, Square (mm) | 180 |
| Shape | Square |
| Maximum Static Pressure (Pa) | (100V)196/245(50/60Hz), (110V)245(60Hz), (115V)245(60Hz) |
Frame Material |
Aluminum die casting |
Mounting Hole Spacing, Square (mm) |
180 |
Shape |
Square |
Maximum Static Pressure (Pa) |
(100V)196/245(50/60Hz), (110V)245(60Hz), (115V)245(60Hz) |
Type |
Set product |
Material (Fan Blade) |
Polycarbonate (flame retardant grade V-0) |
Monotaro ID |
37729212 |
Sound Pressure Level (dB) |
(100V)56/60(50/60Hz), (110V)61(60Hz), (115V)61(60Hz) |
Type of Product |
AC Propeller Fan |
Model No |
T-MRS18-BUL-F |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Maximum Airflow |
(100 V)11/12.8(50/60 Hz), (110 V)12.8(60 Hz), (115 V)12.8(60 Hz) |
Current (A) (50/60Hz) |
(100V)0.8/1(50/60Hz), (110V)1(60Hz), (115V)1(60Hz) |
Set Contents |
Fan, filter, mounting screw (M5X30mm), instruction manual |
Series |
MRS |
Rated Voltage (V) |
Single Phase 100, 110, 115 |
Frame Thickness (mm) |
90 |
Rated Rotation Speed (min⁻¹ [rpm]) |
(100V)2850/3300(50/60Hz), (110V)3350(60Hz), (115V)3350(60Hz) |
Connection Type |
Terminal block |
Additional Functions |
None |
Specifications |
No alarm |
Input (W) |
(100V)54.5/76(50/60Hz), (110V)81(60Hz), (115V)84(60Hz) |
Fan |
MRS18-BUL |
