| Frame Material | Aluminum die casting |
| Mounting Hole Spacing, Square (mm) | 180 |
| Shape | Square |
| Maximum Static Pressure (Pa) | (200V)196/245(50/60Hz), (220V)245(60Hz), (230V)245(60Hz) |
Frame Material |
Aluminum die casting |
Mounting Hole Spacing, Square (mm) |
180 |
Shape |
Square |
Maximum Static Pressure (Pa) |
(200V)196/245(50/60Hz), (220V)245(60Hz), (230V)245(60Hz) |
Type |
Fan single item |
Frequency (Hz) |
50/60 |
Monotaro ID |
37730734 |
Sound Pressure Level (dB) |
(200V)56/60(50/60Hz), (220V)61(60Hz), (230V)61(60Hz) |
Type of Product |
AC Propeller Fan |
Model No |
MRS18-TTM |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Maximum Airflow |
(200 V)11/12.8(50/60 Hz), (220 V)12.8(60 Hz), (230 V)12.8(60 Hz) |
Current (A) (50/60Hz) |
(200V)0.4/0.4(50/60Hz), (220V)0.4(60Hz), (230V)0.4(60Hz) |
Series |
MRS |
Mass (Kg) |
2.5 |
Rated Voltage (V) |
Three-Phase 200, 220, 230 |
Connection Type |
Terminal block |
Operation Mode |
(Normal rotation) L level <Internal transistor ON>, (Alarm output) H level <Internal transistor OFF> |
Additional Functions |
Low rotation alarm + non-contact type |
Specifications |
With alarm |
Alarm Output |
Open collector output |
Input (W) |
(200V)52/70(50/60Hz), (220V)74(60Hz), (230V)76(60Hz) |
