| Frame Material | Aluminum die casting |
| Mounting Hole Spacing, Square (mm) | 250 |
| Shape | Square |
| Maximum Static Pressure (Pa) | (100V)290/320(50/60Hz), (110V)340(60Hz), (115V)360(60Hz) |
Frame Material |
Aluminum die casting |
Mounting Hole Spacing, Square (mm) |
250 |
Shape |
Square |
Maximum Static Pressure (Pa) |
(100V)290/320(50/60Hz), (110V)340(60Hz), (115V)360(60Hz) |
Type |
Set product |
Material (Fan Blade) |
Polycarbonate (flame retardant grade V-0) |
Monotaro ID |
37729562 |
Sound Pressure Level (dB) |
(100V)58/62(50/60Hz), (110V)62(60Hz), (115V)62(60Hz) |
Type of Product |
AC Propeller Fan |
Model No |
T-MRS25-B-G |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Maximum Airflow |
(100 V)21/24(50/60 Hz), (110 V)24(60 Hz), (115 V)24(60 Hz) |
Current (A) (50/60Hz) |
(100V)0.8/1.1(50/60Hz), (110V)1.1(60Hz), (115V)1.1(60Hz) |
Set Contents |
Fan, finger guard, condenser, condenser cap, mounting screw (M5X20mm), instruction manual |
Series |
MRS |
Rated Voltage (V) |
Single Phase 100, 110, 115 |
Frame Thickness (mm) |
120 |
Rated Rotation Speed (min⁻¹ [rpm]) |
(100V)2800/3220(50/60Hz), (110V)3280(60Hz), (115V)3300(60Hz) |
Connection Type |
Lead |
Additional Functions |
None |
Specifications |
No alarm |
Input (W) |
(100V)80/110(50/60Hz), (110V)120(60Hz), (115V)125(60Hz) |
Fan |
MRS25-B |
