| Frame Material | Aluminum die casting |
| Mounting Hole Spacing, Square (mm) | 200 |
| Shape | Square |
| Maximum Static Pressure (Pa) | (100V)221/186(50/60Hz), (110V)255(60Hz), (115V)265(60Hz) |
Frame Material |
Aluminum die casting |
Mounting Hole Spacing, Square (mm) |
200 |
Shape |
Square |
Maximum Static Pressure (Pa) |
(100V)221/186(50/60Hz), (110V)255(60Hz), (115V)265(60Hz) |
Type |
Fan single item |
Frequency (Hz) |
50/60 |
Monotaro ID |
37730761 |
Sound Pressure Level (dB) |
(100V)56/60(50/60Hz), (110V)61(60Hz), (115V)61(60Hz) |
Type of Product |
AC Propeller Fan |
Model No |
MRS20-BUL |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Maximum Airflow |
(100 V)13.2/15.5(50/60 Hz), (110 V)15.5(60 Hz), (115 V)15.5(60 Hz) |
Current (A) (50/60Hz) |
(100V)0.8/1(50/60Hz), (110V)1(60Hz), (115V)1(60Hz) |
Series |
MRS |
Mass (Kg) |
2.5 |
Rated Voltage (V) |
Single Phase 100, 110, 115 |
Connection Type |
Lead |
Additional Functions |
None |
Specifications |
With alarm |
Input (W) |
(100V)75/95(50/60Hz), (110V)95(60Hz), (115V)95(60Hz) |
Capacitor Capacitance (μF) |
6 |
