| Maximum Static Pressure (Pa) | 320(50Hz), 470(60Hz) |
| Ambient Humidity to Use | 85% or less (non-condensing) |
| Frequency (Hz) | 50/60 |
| Monotaro ID | 1050963 |
Maximum Static Pressure (Pa) |
320(50Hz), 470(60Hz) |
Ambient Humidity to Use |
85% or less (non-condensing) |
Frequency (Hz) |
50/60 |
Monotaro ID |
1050963 |
Type of Product |
Square AC Blower |
Model No |
MBS18-THL |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Maximum Airflow |
5.1(50 Hz), 6.0(60 Hz) |
Dimension (mm) |
□180 |
Included Components |
Fan, power cable, wind control louver, mounting screws, instruction manual |
Current (A) (50/60Hz) |
0.35(50Hz), 0.42(60Hz) |
Material |
[Motor case] Aluminum die casting, [Casing] Aluminum die casting, [Runner] Aluminum |
Bearing Type |
ball bearing |
Voltage |
Three-Phase 200 V |
Mass (Kg) |
4.5999999999999996 |
Noise Level (dB (A)) (50/60Hz) |
67(50Hz), 70(60Hz) |
Connection Type |
power cable |
Input (W) |
82(50Hz), 126(60Hz) |
Protection Devices |
Built-in thermal protector |
Paint Color |
Dark gray |
Rotational Speed (RPM) |
2900(50Hz), 3380(60Hz) |
Working Voltage |
±10% |
