| Type of Product | Ultra-Small Basic Switch |
| Part No | 64-3379-60 |
| Model No | SS-3GL111P |
| Rated Voltage (V) | AC 125 |
Type of Product |
Ultra-Small Basic Switch |
Part No |
64-3379-60 |
Model No |
SS-3GL111P |
Rated Voltage (V) |
AC 125 |
Monotaro ID |
46554164 |
Rated Current (A) |
3 |
Mass (g) |
1.6 (in the case of pin push button type) |
Allowable Operating Speed |
0.1Mm To 1 m/s (Pin Pushbutton Type) |
Electric Shock Protection Class |
ClassⅠ |
Terminal Type |
Solder Terminal |
Actuator Type |
Hinge / Long Lever Type |
Mechanical Durability |
1,000,000 times or more (60 times / min) |
Electrical Durability |
70,000 times or more (20 times/min AC 125 V), 100,000 times or more (20 times/min DC 30 V) |
Protection Class |
IEC IP40 |
Allowable Operation Frequency (Times / Min) |
Mechanical: 300, Electrical: 30 |
Operating Temperature Range |
-25 to 85 60% RH or less ℃ (with no icing or condensation) |
Series |
SS-P Series |
Withstand voltage (V / min) |
Between terminals of the same polarity: AC1000 (50/60 Hz), Between live metal parts and earth: AC1500 (50/60 Hz), Between each terminal and non-live metal parts: AC1500 (50/60 Hz) |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Shock Resistance (Malfunction) |
Up to 300 m/s² |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Shock Resistance (m/s²) |
Up to 1000 |
Insulation Resistance (MOhm) |
100 Or More (With Dc500V Insulation Resistance Meter) |
Contact Resistance (ohm) |
less than 50 mΩ |
Operating Humidity (％) |
85 % RH or less (at 5 to 35°C) |
