Showing 11 out of 11 products
Working Pressure : 10.54kg/cm²g (150Psig.) Hyd.(For Water Lines)
Test Pressure : 21.09kg/cm²g (300Psig.) Hyd
Body Material : Cast Iron
Pattern Type : Y Type
End Details : Screwed female BSP Parallel threads to BS-21
Material : Cast Iron
Type of Product : Y Strainer
Trim : SS 304 Screen having 1.2mm perforation
Model No : CI 16
End Connection Type : Screwed
Working Pressure : 20 Kg/cm²g Hyd.
Body Material : ASTM A106 Gr. B
Type : Tee Type
End Details : Flanges Ends as per ASME B 16.5 CL-150 R.F.
Material : Mild Steel
Pressure : CL-150
Type of Product : T Strainer Flanged
Model No : CI 19D
Body Test Pressure : 30 Kg/cm²g Hyd.
Class : CL-150
Product Description : Bolted Bonnet
Screen : 40 Mesh SS 304
Body Material : Cast Iron IS 210 Gr. FG 200
End Details : Flanges as per BS 10 Table E (Drilled)
Material : Cast Iron
Pressure : PN-10
Type of Product : Y Strainer
Trim : SS Screen/ SS 304 having 1.2 mm perforation
Model No : CI 16 C
Body Test Pressure : 21 barg (300 Psig.) Hyd.
Product Type : Y Type stainer (Flanged)
Product Description : Bolted cover
Body Material : Cast Iron
Pattern Type : Y Type
End Details : Flanges as per BS 10 Table F undrilled
Material : Cast Iron
Type of Product : Y Strainer
Trim : S.S. Screen/SS 304 having 1.2mm perforation
Model No : CI 16B
Body Test Pressure : 21.09kg/cm²g (300Psig.) Hyd.(For Water Line)
End Connection Type : Flanged
Working Pressure : Max. BOP 350 Psig. at 400ºC
Test Pressure : 700 Psig. Hyd. 49.23kg/cm²g
Body Material : Cast Steel
Pattern Type : Y-Type
End Details : Flanges as per BS 10 Table J FF undrilled
Material : Cast Steel
Type of Product : Y Strainer
Trim : SS (Type 304) Screen having 1.2mm dia perforation
Model No : CS 3
End Connection Type : Flanged
Working Pressure : 20 Kg/cm²g Hyd.
Body Material : ASTM A106 Gr. B
End Details : Flanges Ends as per ASME B 16.5 CL-150 R.F.
Material : Mild Steel
Pressure : CL-150
Type of Product : Fabricated Y-Strainer Flanged
Model No : CI 16 D
Body Test Pressure : 30 Kg/cm²g Hyd.
Class : CL-150
Product Type : M.S. Fabricated Y-Strainer
Product Description : Bolted Bonnet
Screen : 40 Mesh SS 304
Working Pressure : Max BOP 10.54kgf/cm²g. (150 Psig.) at 220ºC Steam
Test Pressure : 21.09kg/cm² (300 Psig. Hyd.)
Body Material : Cast Iron
Pattern Type : Y-Type
End Details : Flanges as per BS-10 Table F F.F. undrilled
Material : Cast Iron
Type of Product : Y Strainer
Trim : SS 304 Screen having 1.2 mm dia perforation
Model No : CI 7A
End Connection Type : Flanged
Body Material : Cast Steel
Maximum Working Temperature : 400ºC
Pattern Type : Y Type
End Details : Flanges as per BS10 Table F/Class-150
Material : Cast Steel
Type of Product : Y Strainer
Trim : AISI 304, Screen 1.2mm dia perforation
Model No : CS 3 A
Body Test Pressure : 40kg/cm² Hyd.
End Connection Type : Flanged
Maximum Working Pressure : 20kg/cm²
Working Pressure : Max. BOP 250Psig.(17.58 kg/cm² ) at 435ºF(225ºC)
Test Pressure : Tested to 500Psig. Hyd. (35.15 kg/cm² Hyd.)
Pattern Type : Y Type
End Details : Flanges as per BS-10 Table H, FF undrilled
Type of Product : Y Strainer
Model No : IBR 12B
End Connection Type : Flanged
Working Pressure : Max. BOP 250Psig.(17.58 kg/cm²) at 435ºF(225ºC)
Test Pressure : Tested to 500Psig. Hyd. (35.15 kg/cm² Hyd.)
Pattern Type : Y Type
End Details : Screwed Male BSP Taper Thread to BS-21
Type of Product : Y Strainer
Model No : IBR 12A
End Connection Type : Screwed
Working Pressure : Max BOP 13kgf/cm²g. (185 Psig.) at 220ºC Steam
Test Pressure : Body 26kg/cm²g. (370 Psig. ) Hyd.
Body Material : Cast Iron
Pattern Type : Y-Type
End Details : Female BSP Parallel threads to BS-21
Material : Cast Iron
Type of Product : Y Strainer
Trim : SS 304 Screen having 1.2 mm dia perforation
Model No : CI 7B
End Connection Type : Screwed
Page 1 of 1 results
| Product Name | Expected Price | Dispatch Time | Discount |
|---|---|---|---|
| Sant 50 mm Cast Iron Y Type Strainer CI 16 | ₹3,185 | 4 days | 1.61% OFF |
