| Inner Diameter | Φ15 mm |
| Type | Separate Type |
| Country of Origin | Japan |
| Type of Product | Roller Follower |
Inner Diameter |
Φ15 mm |
Type |
Separate Type |
Country of Origin |
Japan |
Type of Product |
Roller Follower |
Model No |
NAST15ZZR |
Dimension B1 (mm) |
16 |
Monotaro ID |
34568624 |
Mass (g) |
83 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
THK Co., Ltd. |
Dimension B (Φmm) |
15.8 |
Limit Speed r/min |
10000 RPM |
RoHS Directive |
Correspondence |
Outer Diameter (Φmm) |
35 |
Dimension d |
Φ15 mm |
Dimension D (Φmm) |
35 |
Special Features |
without seal, with side plate, spherical outer ring |
Load Capacity |
3.14 kN |
Basic Load Rating C (kN) |
12.3 kN |
Basic Load Rating Co (kN) |
14.3 kN |
Dimension A (Φmm) |
29 |
Dimension E2 |
0.8 mm |
Dimension E1 |
2.5 mm |
