| Inner Diameter | Φ12 mm |
| Type | Separate Type |
| Country of Origin | Japan |
| Type of Product | Roller Follower |
Inner Diameter |
Φ12 mm |
Type |
Separate Type |
Country of Origin |
Japan |
Type of Product |
Roller Follower |
Model No |
NAST12 |
Dimension B1 (mm) |
12 |
Monotaro ID |
34568335 |
Mass (g) |
58 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
THK Co., Ltd. |
Dimension B (Φmm) |
11.8 |
Dimension R |
1.5 mm |
Limit Speed r/min |
13000 RPM |
RoHS Directive |
Correspondence |
Outer Diameter (Φmm) |
32 |
Dimension d |
Φ12 mm |
Dimension D (Φmm) |
32 |
Special Features |
without Seal, Cylindrical Outer Ring |
Load Capacity |
5.98 kN |
Basic Load Rating C (kN) |
10.4 kN |
Basic Load Rating Co (kN) |
10.9 kN |
Dimension r1 (mm) |
0.5 |
Dimension Dr (Φmm) |
16 |
