Ships within 25 days
View
View
View
View
| Width (mm) | 7 |
| Type | CF Type |
| Country of Origin | Japan |
| Shape | Cylindrical outer ring |
Width (mm) |
7 |
Type |
CF Type |
Country of Origin |
Japan |
Shape |
Cylindrical outer ring |
Material |
Stainless steel |
Type of Product |
Hexagonal Cam Follower |
Model No |
CF3M-A |
Dimension B1 (mm) |
8 |
Monotaro ID |
6333467 |
Seal |
None |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
THK Co., Ltd. |
Dimension H (Φmm) |
1.5 |
CO (kN) |
1.18 |
Dimension S |
M3x0.5 mm |
C (kN) |
1.47 |
Dimension B (Φmm) |
7 |
Dimension L (mm) |
17 |
Dimension R |
0.3 mm |
Limit Speed r/min |
47000 RPM (Applicable to grease lubrication without seal. Allowable up to 130% of this value for oil lubrication and up to 70% for seal lubrication.) |
Outer Diameter (Φmm) |
10 |
Dimension D1 (mm) |
-(Grease greasing hole is not provided, so re-greasing is not possible.) |
Dimension d |
3 mm |
