Ships within 19 days
Cable Length (m)
Model No
View
View
View
View
| Monotaro ID | 66532418 |
| Type of Product | Round Waterproof Connector |
| Model No | XS3H-M422-401-PR |
| Rated Voltage (V) | DC 125 |
Monotaro ID |
66532418 |
Type of Product |
Round Waterproof Connector |
Model No |
XS3H-M422-401-PR |
Rated Voltage (V) |
DC 125 |
Rated Current (A) |
1 |
Connection |
1 brown 2 white 3 blue 4 black |
No. of Pole |
4 Pole |
Cable |
Oil-resistant (polyurethane) robot cable |
Protection Class |
IP67(IEC529) |
Type |
M8 Type |
Country of Origin |
Japan |
Contact Material |
Phosphor bronze |
Import Country |
Direct Import from Japan |
Cable Direction |
L-shaped |
Operating Temperature Range |
-25 to +70℃ |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Cable Length (m) |
1 |
Withstand voltage (V / min) |
(Connector part) AC 1000 (Leakage current 1 mA or less) |
Cover Material |
Soft PBT (UL94V-0) |
Material (O-ring) |
Rubber |
Tensile Strength |
Cable: 49N / 15s |
Installation |
M8 type |
Material (fixing bracket) |
Brass / nickel plated or SUS316L |
Contact Resistance (ohm) |
(Connector) 40 mΩ or Less (DC 20 mV mΩ or Less, 100 mA mΩ or Less) |
Insulation Resistance (MOhm) |
1000 or more (at DC 500 V) |
Material (Contact Block) |
PBT resin (UL94V-0) / light gray or black |
