| Model No | 20 |
| Type of Product | Ball Valve Socket Type PVC |
| Connection Type | Socket type |
| Country of Origin | Japan |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
20 |
Type of Product |
Ball Valve Socket Type PVC |
Connection Type |
Socket type |
Country of Origin |
Japan |
Seal Material |
EPDM |
Material |
PVC |
Monotaro ID |
29821025 |
Dimension L (mm) |
115 |
Name of Manufacturer/Packer/Importer |
MonotaRO |
Import Country |
Direct Import from Japan |
Maximum Operating Pressure (MPa) |
0.98 or less |
Nominal Diameter (B) |
3/4 |
Connection Direction |
Straight |
Dimensions H (mm) |
59 |
Nominal Diameter (A) |
20 |
Dimension D1 (mm) |
26.2 |
Dimension W |
90 mm |
Dimensions D (mm) |
20 |
Dimension L1 |
25.5 mm |
