| Model No | ADRSZBM |
| Type of Product | Expansion Board |
| Country of Origin | Japan |
| Resolution | Temperature: 0.01 ℃ / Humidity: 0.008% / Atmospheric pressure: 0.18Pa |
Model No |
ADRSZBM |
Type of Product |
Expansion Board |
Country of Origin |
Japan |
Resolution |
Temperature: 0.01 ℃ / Humidity: 0.008% / Atmospheric pressure: 0.18Pa |
Monotaro ID |
62957598 |
Power Supply |
Powered by Raspberry Pi Zero |
Name of Manufacturer/Packer/Importer |
Bit Trade One |
Included Components |
Breadboard jumper wire (male-female) 5, screw set x1 Warranty card x1 |
LED |
Statusx1 |
Import Country |
Direct Import from Japan |
Specifications |
Measurement range and measurement accuracy: Temperature: -40 to + 85 ° C, ± 1 ° C / Humidity: 0 to 100%, ± 3% / Atmospheric pressure: 300 to 1100hPa, ± 1hPa Body weight: Approximately 14g |
Switch Type |
Reboot switch / shutdown switch |
Compatible Models |
Raspberry Pi Zero v1.3 / W / WH (GPIO pin header soldering is required for v1.3 and W) Raspberry Pi 2/3 (If screws cannot be fixed) There is, the restart switch cannot be used) |
Main Unit Dimensions |
W65 x D30 x H23mm (excluding protrusions) |
