| Model No | BWF-21B-CE |
| Type of Product | Optical Data Transmission Device |
| Country of Origin | Japan |
| Monotaro ID | 58764591 |
Model No |
BWF-21B-CE |
Type of Product |
Optical Data Transmission Device |
Country of Origin |
Japan |
Monotaro ID |
58764591 |
Interface |
Input/Output: 20mA current loop/RS-232C |
Name of Manufacturer/Packer/Importer |
Hokuyo Electric Co., Ltd. |
Frequency |
Modulation: Transmit 5.5MHz, Receive 6.0MHz |
Import Country |
Direct Import from Japan |
Protection Class |
IP60 (IEC standard), special specifications available up to IP64 |
Specifications |
Light receiving level output: 0 to 5V (proportional to the amount of light received) |
Mass (g) |
About 500 |
Case Material |
ABS resin |
Transmission distance (m) |
200 |
Transmission Speed |
DC to 9600bps (RS-232C is 19.2 kbps) |
Ambient Illumination to Use (Lx) |
20,000 or less (both sunlight and incandescent light) |
Operating Temperature / Humidity Range |
-10 to +50°C, 85% RH or less. However, no freezing or condensation. Vibration resistant |
Transmission Method |
Full-duplex, two-way transmission |
Alarm Output |
Photocoupler (35 V, 50 mA), ON when light receiving level is 1.5 times or more, OFF when it is less than this<br> Receiving |
Connector |
Connector type (25-pin D sub-connector) but power supply is M3 screw terminal |
Current Consumption (mA) |
150 or less (at DC12V) |
Positioning Angle |
± 2° |
Indicator Lamp |
Power, carrier detection, data input, data output, and light receiving level margin indicators (all red LEDs) |
Power Supply Voltage |
DC12 to 24 V (Operating voltage range DC 10 to 30 V |
Vibration Resistance |
Double amplitude 1.5 mm 10 to 30Hz X, Y, Z each direction 2 hours each |
Shock Resistance |
500 m/s2 10 times each in X, Y, and Z directions |
Applicable Standard |
CE |
