| Model No | BWF-27B |
| Type of Product | Optical Data Transmission Device |
| Country of Origin | Japan |
| Monotaro ID | 58765729 |
Model No |
BWF-27B |
Type of Product |
Optical Data Transmission Device |
Country of Origin |
Japan |
Monotaro ID |
58765729 |
Name of Manufacturer/Packer/Importer |
Hokuyo Electric Co., Ltd. |
Communication Protocol |
CC-Link transmission section: Polling method |
Import Country |
Direct Import from Japan |
Specifications |
●CC-Link transmission unit [Remote station number]: 1 to 64 ●CC-Link transmission unit [Maximum extension distance] *The total extension varies depending on the total number of remote units and the minimum cable length between remote stations. : [Communication speed/When using dedicated cable/When using dedicated high-performance cable] 10Mbps/100m/100m, 5Mbps/150m/160m, 2.5Mbps/200m/400m, 625Kbps/600m/900m, 156Kbps/1200m/1200m●CC-Link transmission section [termination resistor]: 110Ω (connected between the DA-DB units on both ends) switchable●CC-Link transmission section [synchronization method]: Frame synchronization method●Optical transmission section: 200m●Optical transmission section [optical transmission speed]: 19,200bps●Optical transmission section [optical transmission method]: Full-duplex bidirectional transmission●Optical transmission section [beam angle]: ±1°●Optical transmission section [modulation/demodulation frequency]: Type A (transmission 5.5MHz, reception 6.0MHz), Type B (transmission 6.0MHz, reception 5.5MHz)●Optical transmission section [modulation/demodulation method]: FSK modulation |
Mass (g) |
About 500 |
Case Material |
ABS resin |
Transmission Speed |
CC-Link transmission section: 10 mbps/5 mbps/2.5 mbps/625 kbps/156 kbps (switchable) |
Ambient Illumination to Use (Lx) |
20000 or less |
Operating Temperature / Humidity Range |
-10 to +50°C, 85% RH or less. However, no freezing or condensation. |
Current Consumption (mA) |
100 or less (when input voltage is 24V DC) |
Power Supply Voltage |
DC 24 V (18V to 30V) |
Connection Type |
CC-Link transmission section: Connector type, but DC power supply and FG are terminals |
Format Type |
CC-Link transmission section [Transmission]: HDLC compliant |
Transmission Line |
CC-Link transmission section: RS-485 bus |
Vibration Resistance |
Double amplitude 1.5 mm 10~55Hz X, Y, Z each direction 2 hours each |
Connection Cable |
CC-Link transmission part: CC-Link dedicated cable, CC-Link dedicated high-performance cable |
Shock Resistance |
490 m/s2 10 times each in X, Y, Z directions |
