| Model No | CMBZ804016SK |
| Type of Product | Panel Cabinet |
| Color | Beige (Munsell value: 5Y7 / 1) |
| Country of Origin | Japan |
Model No |
CMBZ804016SK |
Type of Product |
Panel Cabinet |
Color |
Beige (Munsell value: 5Y7 / 1) |
Country of Origin |
Japan |
Monotaro ID |
7366265 |
Name of Manufacturer/Packer/Importer |
Naigai Electric Co., Ltd. |
Mass (Kg) |
22.1 |
Import Country |
Direct Import from Japan |
Protection Class |
IP2XD |
Specifications |
Embedded type |
Color (Munsell value) |
5Y7/1 |
Material (Circuit Board) |
Made of iron |
Circuit Board Dimensions, Length x Width (mm) |
720x320 |
Wall Thickness (mm) |
(Door/Body/Front Frame) 1.6 |
Dimension Z (mm) |
122 (effective depth under handle) |
Earth Terminal |
Copper terminal screw M8 x 16 (green head) |
Door Dimensions, Height x Width (mm) |
755x355 |
Substrate Thickness |
2.3 mm |
Paint Color |
Beige |
Handle |
Swing handle (key No. NCH200), small (NCH-13) |
Door Material |
Iron |
Door Opening / Closing Pattern |
One-Sided |
Body Material |
Iron |
Dimensions LengthxWidthxThickness (mm) |
800x400x160 |
Effective Depth (mm) |
140 |
Frame Material |
Iron |
