| Model No | C-MU1238A-11B-GSFCG |
| Type of Product | Control Board AC Fan Unit |
| Material | Cover, frame: polycarbonate (flame retardant grade: V-0), filter media: polyester/modacrylic fan/fan frame: aluminum die-cast, blades: polycarbonate (flame retardant grade: V-0), finger guard: iron wire |
| Country of Origin | Japan |
Model No |
C-MU1238A-11B-GSFCG |
Type of Product |
Control Board AC Fan Unit |
Material |
Cover, frame: polycarbonate (flame retardant grade: V-0), filter media: polyester/modacrylic fan/fan frame: aluminum die-cast, blades: polycarbonate (flame retardant grade: V-0), finger guard: iron wire |
Country of Origin |
Japan |
Monotaro ID |
55683146 |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Current (A) (50/60Hz) |
(50Hz)0.24, (60Hz)0.22 |
Rotational Speed (RPM) |
(50Hz)2750, (60Hz)3070 |
Maximum Airflow |
(50Hz)1.68, (60Hz)1.92 m³/min |
Mass (Kg) |
0.7 |
Cooling Method |
Suction Type |
Input (W) |
(50Hz)17, (60Hz)16.5 |
Filter |
Attached |
Import Country |
Direct Import from Japan |
Noise Level (Dba) |
(50Hz)44, (60Hz)46 |
Maximum Static Pressure (Pa) |
(50Hz)75, (60Hz)79 |
Protection Devices |
Impedance protection |
Mounting Hole Spacing, Square (mm) |
161x158 |
Panel Color |
Cream |
Input Voltage (V) |
Single Phase 100 |
Protection Class |
IP2X |
