| Type | Finger guard unit |
| Model No | C-EMU1238M-GEFG-1 |
| Type of Product | Control Board AC Fan Unit |
| Material | [Cover, Frame] Polycarbonate (Flame Retardant Grade: V-0), [Filter Media] Polyester / Moda Acrylic, [Fan Frame] PBT (Flame Retardant Grade: V-0), [Wings] Polyphenylene Oxide (Flame Retardant Grade: V) -1), [Finger guard] Iron wire |
Type |
Finger guard unit |
Model No |
C-EMU1238M-GEFG-1 |
Type of Product |
Control Board AC Fan Unit |
Material |
[Cover, Frame] Polycarbonate (Flame Retardant Grade: V-0), [Filter Media] Polyester / Moda Acrylic, [Fan Frame] PBT (Flame Retardant Grade: V-0), [Wings] Polyphenylene Oxide (Flame Retardant Grade: V) -1), [Finger guard] Iron wire |
Voltage |
Single Phase 100-240 V |
Country of Origin |
Japan |
Monotaro ID |
55684494 |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Function |
Rotation drop alarm, non-contact type |
Included Components |
Control panel fan unit, power connection plug cord, alarm cable, mounting screw set (tapping screw, speed nut), instruction manual |
Dimension (mm) |
Fan: □ 120 |
Cable Length (m) |
1 |
Current (A) (50/60Hz) |
0.09 |
Rotational Speed (RPM) |
2910 |
Maximum Airflow |
2 m³/min |
Mass (Kg) |
0.46 |
Cooling Method |
Exhaust Type |
Ambient Humidity to Use |
85% or less (20-85% for C-EMU, 65% or less for dust-proof / drip-proof unit, dust-proof / drip-proof panel) (non-condensing) |
Protection Circuit |
Built-in burnout prevention circuit |
Frequency (Hz) |
50/60 |
Filter |
Attached |
Import Country |
Direct Import from Japan |
Thickness (mm) |
Fan: 38 |
Operation Ambient Temperature (°C) |
-10 to +60 (-20 to +75 for C-EMU) |
Noise Level (Dba) |
43 |
