Ships within 25 days
View
View
View
View
| Type | Slit sheet metal unit |
| Model No | C-MU1238A-21B-SECG |
| Type of Product | Control Panel Fan Unit |
| Material | [Cover, frame] SPCC or SPHC thickness 1.6mm, [Filter media] Polyester, [Mounted fan fan frame] Aluminum die casting, [Blade] Polycarbonate (flame retardant grade V-0), [Finger guard] Iron wire |
Type |
Slit sheet metal unit |
Model No |
C-MU1238A-21B-SECG |
Type of Product |
Control Panel Fan Unit |
Material |
[Cover, frame] SPCC or SPHC thickness 1.6mm, [Filter media] Polyester, [Mounted fan fan frame] Aluminum die casting, [Blade] Polycarbonate (flame retardant grade V-0), [Finger guard] Iron wire |
Voltage |
Single Phase 115 V |
Country of Origin |
Japan |
Monotaro ID |
1052765 |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Included Components |
Control panel fan unit, power connection plug cord (1m), mounting screws, instruction manual |
Dimension (mm) |
Fan: □ 119 |
Cable Length (m) |
1 |
Current (A) (50/60Hz) |
50Hz/0.22, 60Hz/0.19 |
Rotational Speed (RPM) |
50Hz/2750, 60Hz/3100 |
Maximum Airflow |
50Hz/0.9, 60Hz/1.0 m³/min |
Mass (Kg) |
1.2 |
Cooling Method |
Exhaust Type |
Ambient Humidity to Use |
85% or less (20-85% for C-EMU, 65% or less for dust-proof / drip-proof unit, dust-proof / drip-proof panel) (non-condensing) |
Input (W) |
50Hz/16.8, 60Hz/16.3 |
Frequency (Hz) |
50/60 |
Filter |
Attached |
Import Country |
Direct Import from Japan |
Thickness (mm) |
Fan: 38 |
Operation Ambient Temperature (°C) |
-10 to +60 (-20 to +75 for C-EMU) |
Noise Level (Dba) |
50Hz/45, 60Hz/48 |
Maximum Static Pressure (Pa) |
50Hz/74, 60Hz/85 |
