Ships within 25 days
View
View
View
View
| Model No | C-MU1238A-11B-GSCG |
| Type of Product | Control Board AC Fan Unit |
| Material | Finger guard panel: Polycarbonate (flame retardant grade: V-0), installed fan / fan frame: aluminum die casting, blade: polycarbonate (flame retardant grade: V-0) Finger guard: iron wire |
| Country of Origin | Japan |
Model No |
C-MU1238A-11B-GSCG |
Type of Product |
Control Board AC Fan Unit |
Material |
Finger guard panel: Polycarbonate (flame retardant grade: V-0), installed fan / fan frame: aluminum die casting, blade: polycarbonate (flame retardant grade: V-0) Finger guard: iron wire |
Country of Origin |
Japan |
Monotaro ID |
55683164 |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Current (A) (50/60Hz) |
(50Hz)0.23, (60Hz)0.2 |
Rotational Speed (RPM) |
(50Hz)2780, (60Hz)3180 |
Maximum Airflow |
(50Hz)2.4, (60Hz)2.7 m³/min |
Mass (Kg) |
0.7 |
Cooling Method |
Suction Type |
Input (W) |
(50Hz)15.9, (60Hz)14.8 |
Import Country |
Direct Import from Japan |
Noise Level (Dba) |
(50Hz)45, (60Hz)48 |
Maximum Static Pressure (Pa) |
(50Hz)80, (60Hz)88 |
Protection Devices |
Impedance protection |
Mounting Hole Spacing, Square (mm) |
161x158 |
Panel Color |
Cream |
Input Voltage (V) |
Single Phase 100 |
Protection Class |
IP2X |
