| Type | Finger guard unit |
| Model No | C-MD1225-24H-GEFG |
| Type of Product | Control Panel Fan Unit |
| Material | [Cover, Frame] Polycarbonate (Flame Retardant Grade V-0), [Filter Media] Polyester / Moda Acrylic, [Fan Frame] Aluminum Die Casting, [Blade] Polycarbonate (Flame Retardant Grade V-0), [Finger Guard] Iron Wire |
Type |
Finger guard unit |
Model No |
C-MD1225-24H-GEFG |
Type of Product |
Control Panel Fan Unit |
Material |
[Cover, Frame] Polycarbonate (Flame Retardant Grade V-0), [Filter Media] Polyester / Moda Acrylic, [Fan Frame] Aluminum Die Casting, [Blade] Polycarbonate (Flame Retardant Grade V-0), [Finger Guard] Iron Wire |
Voltage |
DC 24 V |
Country of Origin |
Japan |
Monotaro ID |
1051042 |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Included Components |
Control panel fan unit, extension cable (1 m), mounting screw set (tapping screw, speed nut), instruction manual |
Dimension (mm) |
Fan: □ 119 |
Cable Length (m) |
1 |
Current (A) (50/60Hz) |
0.27 |
Rotational Speed (RPM) |
2900 |
Maximum Airflow |
1.4 m³/min |
Mass (Kg) |
0.36 |
Cooling Method |
Exhaust Type |
Ambient Humidity to Use |
85% or less (20-85% for C-EMU, 65% or less for dust-proof / drip-proof unit, dust-proof / drip-proof panel) (non-condensing) |
Protection Circuit |
Built-in burnout prevention circuit |
Filter |
Attached |
Import Country |
Direct Import from Japan |
Thickness (mm) |
Fan: 25 |
Operation Ambient Temperature (°C) |
-10 to +60 (-20 to +75 for C-EMU) |
Noise Level (Dba) |
51 |
Maximum Static Pressure (Pa) |
44 |
Working Voltage |
±15% |
