| Type | Finger guard unit |
| Model No | C-EMU938-GSBG-2 |
| Type of Product | Control Board AC Fan Unit |
| Material | [Finger guard panel] Polycarbonate (flame retardant grade: V-0), [Fan frame] PBT (flame retardant grade: V-0), [Blade] PBT (flame retardant grade: V-0), [Finger guard] Iron wire |
Type |
Finger guard unit |
Model No |
C-EMU938-GSBG-2 |
Type of Product |
Control Board AC Fan Unit |
Material |
[Finger guard panel] Polycarbonate (flame retardant grade: V-0), [Fan frame] PBT (flame retardant grade: V-0), [Blade] PBT (flame retardant grade: V-0), [Finger guard] Iron wire |
Voltage |
Single Phase 100-240 V |
Country of Origin |
Japan |
Monotaro ID |
55683724 |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Included Components |
Control panel fan unit, power connection plug cord, mounting screw set (tapping screw, speed nut), instruction manual |
Dimension (mm) |
Fan: □ 92 |
Cable Length (m) |
2 |
Current (A) (50/60Hz) |
0.09 |
Rotational Speed (RPM) |
3750 |
Maximum Airflow |
1.4 m³/min |
Mass (Kg) |
0.36 |
Cooling Method |
Suction Type |
Ambient Humidity to Use |
85% or less (20-85% for C-EMU, 65% or less for dust-proof / drip-proof unit, dust-proof / drip-proof panel) (non-condensing) |
Protection Circuit |
Built-in burnout prevention circuit |
Input (W) |
5.0999999999999996 |
Frequency (Hz) |
50/60 |
Import Country |
Direct Import from Japan |
Thickness (mm) |
Fan: 38 |
Operation Ambient Temperature (°C) |
-10 to +60 (-20 to +75 for C-EMU) |
Noise Level (Dba) |
45 |
Maximum Static Pressure (Pa) |
80 |
