| Type | Slit sheet metal unit |
| Model No | C-MDS1225-24H-SS3G |
| Type of Product | Control Panel Fan Unit |
| Material | [Cover, frame] SPCC or SPHC thickness 1.6mm, [Filter media] Polyester, [Fan frame] Aluminum die casting, [Blade] Polycarbonate (flame retardant grade V-0), [Finger guard] Iron wire |
Type |
Slit sheet metal unit |
Model No |
C-MDS1225-24H-SS3G |
Type of Product |
Control Panel Fan Unit |
Material |
[Cover, frame] SPCC or SPHC thickness 1.6mm, [Filter media] Polyester, [Fan frame] Aluminum die casting, [Blade] Polycarbonate (flame retardant grade V-0), [Finger guard] Iron wire |
Voltage |
DC 24 V |
Country of Origin |
Japan |
Monotaro ID |
1051873 |
Name of Manufacturer/Packer/Importer |
Oriental Motor Co., Ltd. |
Included Components |
Control panel fan unit, extension cable (1m), mounting screws, instruction manual |
Dimension (mm) |
Fan: □ 119 |
Cable Length (m) |
1 |
Current (A) (50/60Hz) |
1 |
Rotational Speed (RPM) |
3000 |
Maximum Airflow |
3.4 m³/min |
Mass (Kg) |
2.5 |
Cooling Method |
Suction Type |
Ambient Humidity to Use |
85% or less (20-85% for C-EMU, 65% or less for dust-proof / drip-proof unit, dust-proof / drip-proof panel) (non-condensing) |
Protection Circuit |
Built-in burnout prevention circuit |
Filter |
Attached |
Import Country |
Direct Import from Japan |
Thickness (mm) |
Fan: 25 |
Operation Ambient Temperature (°C) |
-10 to +60 (-20 to +75 for C-EMU) |
Noise Level (Dba) |
56 |
Maximum Static Pressure (Pa) |
58 |
Working Voltage |
±15% |
