ORIENTAL MOTOR Control Panel Fan Unit Suction Type Single Phase 220/230 V, C-MU1225S-51-SSC3G

Name: ORIENTAL MOTOR Control Panel Fan Unit Suction Type Single Phase 220/230 V, C-MU1225S-51-SSC3G
Brand: Oriental motor
SKU: IND.CON.639316991
Price: 41299 INR
Availability: InStock

Visit the Oriental motor Store

EMI starts at ₹3669/month. No Cost EMI available.

Available offers

Get Flat 10% off on your First Orders above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 3% off on First Order above ₹3,000

View

Features

Type	Slit sheet metal unit
Model No	C-MU1225S-51-SSC3G
Type of Product	Control Panel Fan Unit
Material	[Cover, frame] SPCC or SPHC thickness 1.6mm, [Filter media] Polyester, [Fan frame] Aluminum die casting, [Blade] Polycarbonate (flame retardant grade V-0), [Finger guard] Iron wire

More Oriental motor Controller Boards products More Controller Boards products

100% Original Products

Secure Payments

100% Buyer Protection

Top Brands

specifications

Type	Slit sheet metal unit
Model No	C-MU1225S-51-SSC3G
Type of Product	Control Panel Fan Unit
Material	[Cover, frame] SPCC or SPHC thickness 1.6mm, [Filter media] Polyester, [Fan frame] Aluminum die casting, [Blade] Polycarbonate (flame retardant grade V-0), [Finger guard] Iron wire
Voltage	Single Phase 220 V / Single Phase 230 V
Country of Origin	Japan
Monotaro ID	1052537
Name of Manufacturer/Packer/Importer	Oriental Motor Co., Ltd.
Included Components	Control panel fan unit, power connection plug cord (1m), mounting screws, instruction manual
Dimension (mm)	Fan: □ 119
Cable Length (m)	1
Current (A) (50/60Hz)	Single-phase 220V / 50Hz / 0.19, Single-phase 230V / 50Hz / 0.20, Single-phase 230V / 60Hz / 0.18
Rotational Speed (RPM)	Single-phase 220V / 50Hz: 2500, Single-phase 230V / 50Hz: 2500, Single-phase 230V / 60Hz: 2800
Maximum Airflow	Single-phase 220V / 50Hz: 2.3, Single-phase 230V / 50Hz: 2.3, Single-phase 230V / 60Hz: 2.7 m³/min
Mass (Kg)	2.5
Cooling Method	Suction Type
Ambient Humidity to Use	85% or less (20-85% for C-EMU, 65% or less for dust-proof / drip-proof unit, dust-proof / drip-proof panel) (non-condensing)
Input (W)	Single-phase 220V / 50Hz / 35.8, Single-phase 230V / 50Hz / 38.2, Single-phase 230V / 60Hz / 33.6
Frequency (Hz)	50/60
Filter	Attached
Import Country	Direct Import from Japan
Thickness (mm)	Fan: 25
Operation Ambient Temperature (°C)	-10 to +60 (-20 to +75 for C-EMU)
Noise Level (Dba)	Single-phase 220V / 50Hz: 47, Single-phase 230V / 50Hz: 47, Single-phase 230V / 60Hz: 50
Maximum Static Pressure (Pa)	Single-phase 220V / 50Hz: 39, Single-phase 230V / 50Hz: 41, Single-phase 230V / 60Hz: 42
