ORIENTAL MOTOR Control Panel Fan Unit Exhaust Type Single Phase 220/230 V, C-MU1238A-51B-SEG

Name: ORIENTAL MOTOR Control Panel Fan Unit Exhaust Type Single Phase 220/230 V, C-MU1238A-51B-SEG
Brand: Oriental motor
SKU: IND.CON.839317510
Price: 15339 INR
Availability: InStock

Visit the Oriental motor Store

EMI starts at ₹1363/month. No Cost EMI available.

Available offers

Flat ₹400 off on Order above ₹10,000 | Valid for REPEAT Business User

View

Flat ₹800 off on Order above ₹20,000 | Valid for REPEAT Business User

View

Flat ₹200 off on Order above ₹6000 | Valid for REPEAT Business User

View

Flat ₹400 off on Order above ₹10,000 | Valid for NEW Business Users

View

Features

Type	Slit sheet metal unit
Model No	C-MU1238A-51B-SEG
Type of Product	Control Panel Fan Unit
Material	[Cover, frame] SPCC or SPHC thickness 1.6mm, [Filter media] Polyester, [Mounted fan fan frame] Aluminum die casting, [Blade] Polycarbonate (flame retardant grade V-0), [Finger guard] Iron wire

More Oriental motor Controller Boards products More Controller Boards products

Warranty as Per Brand

100% Original Products

Secure Payments

100% Buyer Protection

Top Brands

specifications

Type	Slit sheet metal unit
Model No	C-MU1238A-51B-SEG
Type of Product	Control Panel Fan Unit
Material	[Cover, frame] SPCC or SPHC thickness 1.6mm, [Filter media] Polyester, [Mounted fan fan frame] Aluminum die casting, [Blade] Polycarbonate (flame retardant grade V-0), [Finger guard] Iron wire
Voltage	Single Phase 220 V / Single Phase 230 V
Country of Origin	Japan
Monotaro ID	1053054
Name of Manufacturer/Packer/Importer	Oriental Motor Co., Ltd.
Included Components	Control panel fan unit, power connection plug cord (1m), mounting screws, instruction manual
Dimension (mm)	Fan: □ 119
Cable Length (m)	1
Current (A) (50/60Hz)	Single-phase 220V / 50Hz / 0.10, single-phase 230V / 50Hz / 0.10, single-phase 230V / 60Hz / 0.09
Rotational Speed (RPM)	Single-phase 220V / 50Hz: 2750, Single-phase 230V / 50Hz: 2750, Single-phase 230V / 60Hz: 3100
Maximum Airflow	Single-phase 220V / 50Hz: 0.9, Single-phase 230V / 50Hz: 0.9, Single-phase 230V / 60Hz: 1.0 m³/min
Mass (Kg)	1.2
Cooling Method	Exhaust Type
Ambient Humidity to Use	85% or less (20-85% for C-EMU, 65% or less for dust-proof / drip-proof unit, dust-proof / drip-proof panel) (non-condensing)
Input (W)	Single-phase 220V / 50Hz / 16.8, single-phase 230V / 50Hz / 16.8, single-phase 230V / 60Hz / 16.3
Frequency (Hz)	50/60
Filter	Attached
Import Country	Direct Import from Japan
Thickness (mm)	Fan: 38
Operation Ambient Temperature (°C)	-10 to +60 (-20 to +75 for C-EMU)
Noise Level (Dba)	Single-phase 220V / 50Hz: 45, Single-phase 230V / 50Hz: 45, Single-phase 230V / 60Hz: 48
Maximum Static Pressure (Pa)	Single-phase 220V / 50Hz: 74, Single-phase 230V / 50Hz: 74, Single-phase 230V / 60Hz: 85
