| Type of Product | AC / DC Converter Compact and High Efficiency SV Series |
| Model No | SVM12SA |
| Country of Origin | Japan |
| No. Of Output | Single |
Type of Product |
AC / DC Converter Compact and High Efficiency SV Series |
Model No |
SVM12SA |
Country of Origin |
Japan |
No. Of Output |
Single |
Monotaro ID |
76719896 |
Name of Manufacturer/Packer/Importer |
ARS (Eta Electric) |
Maximum Output Voltage |
DC 13.2 V |
Import Country |
Direct Import from Japan |
Rated Input Voltage (V) |
AC100 |
Shape |
Case Type |
Rated Output Voltage (V) |
DC12 |
Terminal Shape |
Screw terminal |
Rated Output Current (A) |
1.3 |
RoHS Directive |
Correspondence |
Input Voltage (V) |
AC85 to 132/DC110 to 175 |
Mass (Kg) |
0.13 |
Rated Output Power (W) |
15.6 |
Dimension (mm) |
20x60x83 (excluding terminal block) |
Capacity |
15.6 W |
Maximum Output Current (A) |
1.3 |
Maximum Input Voltage (V) |
AC132/DC175 |
