PATLITE Interface Converter Main unit: DC24, AC adapter: AC100-240 (50/60 Hz) Number of contacts: 8, NBM-D88N

Name: PATLITE Interface Converter Main unit: DC24, AC adapter: AC100-240 (50/60 Hz) Number of contacts: 8, NBM-D88N
Brand: PATLITE
SKU: IND.CON.543000763
Price: 141599 INR
Availability: InStock

Visit the PATLITE Store

EMI starts at ₹12581/month. No Cost EMI available.

Available offers

Get Flat 10% off on your First Orders above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 3% off on First Order above ₹3,000

View

Features

Type of Product	Interface Converter
Interface	Ethernet (Communication)
Model No	NBM-D88N
Country of Origin	Japan

More PATLITE Converters products More Converters products

100% Original Products

Secure Payments

100% Buyer Protection

Top Brands

specifications

Type of Product	Interface Converter
Interface	Ethernet (Communication)
Model No	NBM-D88N
Country of Origin	Japan
Included Components	AC adapter, simple instruction manual, rubber feet (4)
Outer Dimensions	266x42x137.5 mm
Monotaro ID	40696514
Ambient Humidity to Use	20% to 85% RH (no condensation)
Protection Class	IP65 (IEC 60529) / IP54 (IEC 60529) / NEMA TYPE 4x13 Environmental conditions: When installed in the upright position
Name of Manufacturer/Packer/Importer	Patlite Corporation
Operating Temperature Range	0 to 40℃ (no freezing or condensation)
Mass (g)	Body: 1150, AC adapter: 165
Withstand Voltage	Between charged metal parts and non-charged metal parts: 1,500 VAC, 10 mA or less
Import Country	Direct Import from Japan
Input	Supported input contacts: Non-voltage contacts, NPN transistor Number of contacts: 8 points, Contact rating: Output ON current 6mA or less / Terminal voltage 24V when port is OFF Compatible wire diameter, solid wire: Φ0.4 to 1.2 mm (AWG26-16) Stranded wire: 0.2 to 1.25 (m/ <sup>s2</sup> ) AWG24-16) Wiring method: Screwless terminal block
Applicable Standard	EMC Directive (EN55032 (Class A), EN55035), RoHS Directive (ENIEC63000), FCCPart15subpartB(Class A)
Insulation Resistance (MOhm)	Between live metal parts and non-live metal parts: DC500V/10 or more
operations type	Select switch, reset switch, clear switch, mode switch
Terminal Fitting Type	Deferred / Eia Rack Mounting (Optional)
Output	Number of contacts: 8, Contact rating: Port 1-7: 3A, AC125V/3A, DC30V inrush current 5A or less, minimum 1mA/DC5V (reference value), Port 8: 3A, AC125V/3A, DC30V inrush current 78A or less (TV-5 rating), minimum 10mA/DC5V, Compatible wire diameter: Solid wire: ?0.4 to 1.2 mm (AWG26-16), Stranded wire: 0.2 to 1.25 (m/ <sup>s2</sup> ) (AWG24-16), Wiring method: Screwless terminal block
Communication Protocol	LAN communication, Physical layer: Ethernet (IEEE802.3 compliant) 10BASE-T/100BASE-TX (auto-negotiation, full duplex/half duplex), Connector shape: RJ-45 type 8 poles, Data link layer: CSMA/CD method, Network layer: IP, ARP, ICMP, Transport layer: TCP, UDP, Application layer: HTTP, NTP, Socket (PHN, PNS), SMTP, SNMP (v1, v2c), DHCP, DNS, POP3, RSH
Rated Voltage (V)	Main unit: DC24, AC adapter: AC100-240 (50/60 Hz)
Location	Indoor
Power Consumption (W)	14
Display Type	18 green LEDs (1 power, 1 status, 8 DO, 8 DI)
Operation Ambient Temperature (°C)	0 to 40 (no freezing or condensation)
