| Type of Product | Thermocouple Temperature Converter |
| Model No | WVP-RB-18J-1 |
| Accuracy | (Standard) ±0.4% FS (at 23°C) |
| Power Consumption | (Current) Approximately 4 VA |
Type of Product |
Thermocouple Temperature Converter |
Model No |
WVP-RB-18J-1 |
Accuracy |
(Standard) ±0.4% FS (at 23°C) |
Power Consumption |
(Current) Approximately 4 VA |
Country of Origin |
Japan |
Monotaro ID |
42525036 |
Insulation Resistance |
100 MΩ or more (DC 500 V) (Between Input, Output and Power Terminals) |
Name of Manufacturer/Packer/Importer |
Watanabe Electric Industry Co., Ltd |
Mass (g) |
About 400 |
Import Country |
Direct Import from Japan |
Specifications |
Zero/span adjustment range: ±20% fs (multi-turn trimmer), Cold junction compensation temperature: -5 to +55°C, Wiring part: M3.5 sems screw part of base socket (tightening torque 0.8 Nm) |
Outer Dimensions (mm) |
117(H)x51(W)x126(D) |
Load Resistance |
(Tolerance) 10 kΩ or more |
Case Material |
Heat-Resistant ABS Resin (UL94V-0) |
Function |
Insulation, linearizer function: Yes (R thermocouple 30% fs or less is outside the linearization range), burnout function: Upper limit |
Response Speed |
Approximately 200 ms (0 to 90%) |
Temperature Characteristics |
±0.02% fs/℃ |
Case Color |
Ivory Color |
Structure |
Plug-In (Consists of a Main Body and a Socket) |
Operating Temperature / Humidity Range |
-5 to +55℃ 90% RH or less (non-condensing) |
Power Supply Voltage |
AC 100 V ±10%(50/60 Hz) |
Type of Sign |
DIN Rail Mounting or Wall Mounting |
