| Type of Product | Isolation Converter |
| Model No | TW-1X-01C |
| Accuracy | (Standard) ±0.25% fs (at 25°C ±2°C) |
| Power Consumption | (current) 40 mA or less |
Type of Product |
Isolation Converter |
Model No |
TW-1X-01C |
Accuracy |
(Standard) ±0.25% fs (at 25°C ±2°C) |
Power Consumption |
(current) 40 mA or less |
Country of Origin |
Japan |
Included Components |
Terminal cover, detachable 6P connector |
Monotaro ID |
42591353 |
Insulation Resistance |
100 mΩ or more (DC 500 V) (between input, output and power terminals) |
Name of Manufacturer/Packer/Importer |
Watanabe Electric Industry Co., Ltd |
Mass (g) |
About 130 |
Import Country |
Direct Import from Japan |
Outer Dimensions (mm) |
98(H)×48(W)×41(D) |
Terminal Shape |
(Input/Output) Connector |
Load Resistance |
(Tolerance) 2 kΩ or more |
Case Material |
PBT resin (UL94V-0) |
Response Speed |
Approximately 50 ms (0 to 90%) |
Temperature Characteristics |
±0.02%fs/℃(TYP) |
Case Color |
Black |
Operating Temperature / Humidity Range |
-5℃ to +50℃ 90%RH or less (non-condensing) |
Power Supply Voltage |
AC 100 to 240 V ±10% |
Storage Temperature/Humidity Range |
-10 to +70℃ 90%RH or less (non-condensing) |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) (between input, output and power terminals) |
