| Type of Product | DC San Ace Low Power Consumption Fan |
| Model No | 9GA0412P3M01 |
| Country of Origin | Japan |
| Type | DC fan |
Type of Product |
DC San Ace Low Power Consumption Fan |
Model No |
9GA0412P3M01 |
Country of Origin |
Japan |
Type |
DC fan |
Name of Manufacturer/Packer/Importer |
Sanyo Denki Co., Ltd. |
Size (mm) |
40x40 |
Pack of |
1 Pcs |
Shape |
Square |
Features |
Low power consumption |
Storage Temperature Range |
-30 to +70℃ (no condensation) |
Import Country |
Direct Import from Japan |
Input Voltage (V) |
DC12 V |
Monotaro ID |
47142742 |
Maximum Airflow (m³/min) |
0.46 |
Mass (g) |
53 |
Maximum Static Pressure (Pa) |
258 |
Operating Temperature Range |
-20 to +70°C |
Sound Pressure Level (dB) |
47 |
Material (Fan Blade) |
Resin (Flame retardant grade UL94V-0) |
Thickness (mm) |
28 |
Frame Material |
Resin (Flame retardant grade UL94V-0) |
Rated Rotation Speed (min⁻¹ [rpm]) |
12500 |
Lead Wire |
(+) Red, (-) Black, (Sensor) Yellow, (Control) Brown |
Expected Life (hours) |
40000(60℃), 70000(40℃) |
Rated input (W) |
2.52 |
Rated Current (A) |
0.21 |
Operating Voltage Range (V) |
10.8 to 13.2 |
