| Type of Product | DC San Ace DC Fan 9GV |
| Model No | 9GV1224P1J011 |
| Country of Origin | Japan |
| Type | DC fan |
Type of Product |
DC San Ace DC Fan 9GV |
Model No |
9GV1224P1J011 |
Country of Origin |
Japan |
Type |
DC fan |
Name of Manufacturer/Packer/Importer |
Sanyo Denki Co., Ltd. |
Size (mm) |
120x120 |
Pack of |
1 Pcs |
Shape |
Square |
Import Country |
Direct Import from Japan |
Input Voltage (V) |
DC24 V |
Monotaro ID |
47137456 |
Maximum Airflow (m³/min) |
(PWM：100%)6.35 |
Maximum Static Pressure (Pa) |
(PWM：100%)360 |
Operating Temperature Range |
-20 to +70°C |
Sound Pressure Level (dB) |
(PWM：100%)64 |
Material (Fan Blade) |
Resin (flame retardant grade UL94V-1) |
Thickness (mm) |
38 |
Frame Material |
Resin (Flame retardant grade UL94V-0) |
Rated Rotation Speed (min⁻¹ [rpm]) |
(PWM：100%)6400 |
Rated input (W) |
(PWM：100%)36 |
Rated Current (A) |
(PWM：100%)1.5 |
Operating Voltage Range (V) |
20.4 to 27.6 |
