Ships within 19 days
Model No
View
View
View
View
| Type | Voltage Sensor |
| Model No | SDV-DM2-DC24 |
| Type of Product | Voltage Sensor |
| Operating Time | Operation time 0.5 seconds or less (For overvoltage setting: When the operation value changes from 80% to 120%, for undervoltage setting: When the operation value changes from 120% to 80%) |
Type |
Voltage Sensor |
Model No |
SDV-DM2-DC24 |
Type of Product |
Voltage Sensor |
Operating Time |
Operation time 0.5 seconds or less (For overvoltage setting: When the operation value changes from 80% to 120%, for undervoltage setting: When the operation value changes from 120% to 80%) |
Error |
(Setting error) center voltage ± 2%, dead zone ± 1% |
Withstand Voltage |
AC 2000 V 1 min (between all electrical circuits and outer box, between input terminal and power supply terminal) |
Shock Resistance |
294 m/s² |
Monotaro ID |
46652155 |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
16.7 Hz Double amplitude 1 mm 3 directions 10min |
Influence of Temperature |
Center voltage, dead band (1): ±2%, (2): ±4%, (1) 0 to 40°C (2) -10 to 55°C (However, for SDV-FL 4 to 12mV range (1) ±4% (2) ±8%) |
Operation Type |
Double Operation Type (Overvoltage And Undervoltage Detection) |
Control Power Supply |
DC 24 V |
Input |
For direct current and alternating current (switched by switch) |
Vibration Resistance (Destruction) |
10-25Hz Double amplitude 2 mm (up to 19.6 m/s² ) 3 directions 2h |
Timer Function |
None |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Withstand voltage (V / min) |
Between the entire electrical circuit and the outer box, between the input terminal and the power terminal: AC2000V |
Insulation Resistance (MOhm) |
10 or more (between electrical circuit and outer box, between input terminal and power supply terminal) (at 500 V DC) |
Specifications |
[Waveform effect] Center voltage, dead zone ±3%, When applying a commercial frequency single-phase full-wave input (DC input range) |
