| Type | Voltage Sensor |
| Model No | SDV-DH4E |
| Type of Product | Voltage Sensor |
| Operating Time | Operation time 0.5 seconds or less (For overvoltage setting: When the operation value changes from 80% to 120%, for undervoltage setting: When the operation value changes from 120% to 80%) |
Type |
Voltage Sensor |
Model No |
SDV-DH4E |
Type of Product |
Voltage Sensor |
Operating Time |
Operation time 0.5 seconds or less (For overvoltage setting: When the operation value changes from 80% to 120%, for undervoltage setting: When the operation value changes from 120% to 80%) |
Error |
(Setting error) center voltage ± 2%, dead zone ± 1% |
Influence of Frequency |
Center voltage, dead band ±1%, When AC input changes from 20 to 500 Hz (input side) |
Monotaro ID |
46652085 |
Lightning Impulse Withstand Voltage |
± 1.2 × 50μs 4500V (between electric circuit and outer box) ± 1.2 × 50μs 3000V (between power terminals) |
Import Country |
Direct Import from Japan |
Influence of Temperature |
Center voltage, dead band (1): ±2%, (2): ±4%, (1) 0 to 40°C (2) -10 to 55°C (However, for SDV-FL 4 to 12mV range (1) ±4% (2) ±8%) |
Operation Type |
Double Operation Type (Overvoltage And Undervoltage Detection) |
Control Power Supply |
DC 100/110 V |
Input |
For direct current and alternating current (switched by switch) |
Influence of Control Power |
Center voltage, dead band ±1%, DC power fluctuation range: 80 to 130%, AC power fluctuation range: 85 to 110% |
Timer Function |
None |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Withstand voltage (V / min) |
Between the entire electrical circuit and the outer box, between the input terminal and the power terminal: AC2000V |
Insulation Resistance (MOhm) |
10 or more (between electrical circuit and outer box, between input terminal and power supply terminal) (at 500 V DC) |
Specifications |
[Waveform effect] Center voltage, dead zone ±3%, When applying a commercial frequency single-phase full-wave input (DC input range) |
