Ships within 18 days
Model No
View
View
View
View
| Type of Product | Magnetic Proximity Sensor |
| Model No | GLS-1L |
| Type | Cord Drawer Type |
| Cable Length (m) | 1 |
Type of Product |
Magnetic Proximity Sensor |
Model No |
GLS-1L |
Type |
Cord Drawer Type |
Cable Length (m) |
1 |
Material |
ABS |
Protection Class |
IEC standard IP62 |
Detection Distance |
15 mm |
Series |
GLS Series |
Response Frequency (Hz) |
20 Hz or less |
Monotaro ID |
39071426 |
Withstand Voltage |
AC1000V 1min between each terminal and case (Contact: DC250V 1min Leak current 1mA or less) |
Ambient Temperature (℃) |
During Operation And Storage: -20 To 60 (But Do Not Allow Freezing Or Condensation) |
Detection Distance (mm) |
15 |
Ambient Humidity (% RH) |
Operation and storage: 35 to 85 each (with no condensation) |
Country of Origin |
Japan |
Contact Capacity |
Maximum voltage: DC100 V, Maximum current: DC0.1 A, Maximum contact capacity: 10 W (including opening and closing) |
Service Life |
50,000,000 times or more (at 24VDC 0.1A resistive load) |
Contact Resistance |
250 or less (including conductor resistance of Lead wire) |
Circuits |
(contact) 1a |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Vibration Resistance (Destruction) |
10 to 55 Hz, 1.5 mm double amplitude, 2 hours each in X, Y, and Z directions |
Shock Resistance (m/s²) |
300 m/s² X?Y?Z??? 3? |
Main Unit Material |
ABS |
Material (Switch Part) |
ABS |
Category |
Cylindrical Proximity Sensor |
