Ships within 19 days
Cable Length (m)
Model No
View
View
View
View
| Type of Product | Proximity Sensor Flat Type |
| Model No | TL-W5MD1 2M |
| Type | Rectangular, Unshielded Type |
| Cable Length (m) | 2 |
Type of Product |
Proximity Sensor Flat Type |
Model No |
TL-W5MD1 2M |
Type |
Rectangular, Unshielded Type |
Cable Length (m) |
2 |
Output |
DC 2-wire type |
Case Material |
Heat resistant ABS |
Hysteresis |
10% or less of detection distance |
Control Output |
Switching capacity: 3 to 100 mA, residual voltage: 3.3 V or less (when load current is 100 mA and cord length is 2 m) |
Connection Type |
Cord drawer type |
Protection Circuit |
Load short-circuit protection, surge absorption |
Series |
TL-W Series |
Insulation Resistance |
50 or more (at 500 VDC) between live parts and case |
Power Supply Voltage |
DC12-24 Ripple (pp) 10% or less |
Response Frequency (Hz) |
500 (average value) |
Monotaro ID |
2501852 |
Sensor Shape |
Square |
Setting Distance (mm) |
0～4 |
Detection Target |
Magnetic metal (Non-magnetic metal decreases the detection distance.) |
Accessories Included |
instruction manual |
Influence by Temperature |
± 10% or less of detection distance at + 23 ° C within the temperature range of -25 to + 70 ° C |
Material (Detection Surface) |
Heat resistant ABS |
Withstand voltage (V) |
AC1000 50 / 60Hz 1min Between current-carrying parts and case |
Shield Shape |
Unshielded |
Vibration Resistance (Endurance) |
10 to 55 Hz, 1.5 mm double amplitude, 2 hours each in X, Y, and Z directions |
Standard Sensing Object (mm) |
Iron 18 × 18 × 1 |
Influence of Voltage |
± 2.5% or less of sensing distance at rated power voltage within the rated power voltage ± 15% range |
Operating Voltage Range (V) |
DC10～30 |
Ambient Temperature (℃) |
Operating and storage: -25 to +70 each (with no icing or condensation) |
Detection Distance (mm) |
5 |
Current Consumption (mA) |
- |
Leakage Current (mA) |
0.8 or less |
Ambient Humidity (% RH) |
Operating and storage: 35 to 95 each (no condensation) |
Indicator Lamp |
Operation indicator (red), setting indicator (green) |
shock Resistance (m per s2) |
500 X, Y, Z directions 3 times |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
