UL Group DC Relay Module with 1 C/O Contact and 24 V DC Operating Voltage

UL Group DC Relay Module with 1 C/O Contact and 24 V DC Operating Voltage
Specifications check

Rated Voltage : 250 V

Specifications check

Type of Product : DC Relay Module

Specifications check

Country of Origin : India

Specifications check

Mounting Type : Din Rail Mountable

Specifications check

Name of Manufacturer/Packer/Importer : Explore Technologies

Specifications check

Standard : EN 60947-5-1/ IEC 947-5-1

Specifications check

Contact Current Rating : 12 A at 24 V DC

Specifications check

Cross section : 2.5 sq. mm

Specifications check

Contact Type : 1 Change Over

Specifications check

Ambient Temperature : 0°C to +60°C, Relay Socket: -45 to +120˚C

Specifications check

Stripping Length : 8 mm

Specifications check

Type : with 1 C/O Contact

Specifications check

Insulation Material : PA/I

Specifications check

Rated Current : 25 mA

Specifications check

Operating Voltage : 24 V DC

Specifications check

Nominal Current : 24 A

Specifications check

Loop : Positive/Negative: User Selectable using Jumpers

Specifications check

Tightening Torque : 0.6 Nm Max.

Specifications check

Mechanical Operations : 18000 /hr

Specifications check

Maximum Switching Voltage : 440 V AC, 300 V DC

Specifications check

LED Status : Input: Green

Specifications check

Relative Humidity : Max. 90% (Non-condensing)

Specifications check

Approval : CE

Specifications check

Electrical : Operation: 1800 / hr

Specifications check

Insulation Resistance : 1000 MΩ at 500 V DC

Specifications check

Terminal : UL, CSA Standard & CE standard

Specifications check

Rated : 5 A AC/DC, 250 V rms

Specifications check

Rated Surge Voltage : 4 kV

Specifications check

Contact Configuration : SPDT, Potential Free

Specifications check

Dielectric Strength : Between Contacts: 1000 V AC, 50/60 Hz, 1 min., Relay Socket: 2000 V AC rms for 1 min.

Specifications check

Back E.M.F : Free-wheeling Diode

Specifications check

Terminal Type : Screw Terminal

Sort
sku-leadTime Ships within 12 days
SKU ID: IND.DCR.538097444
UL Group DC Relay Module with 1 C/O Contact, Size 74x90 mm and 24 V DC Operating Voltage, UL24D04-COB
Size
74x90 mm
₹1,297
sku-leadTime Ships within 12 days
SKU ID: IND.DCR.638097434
UL Group DC Relay Module with 1 C/O Contact, Size 134x90 mm and 24 V DC Operating Voltage, UL24D08-COB-V1
Size
134x90 mm
₹1,769
