| Load Regulation | 20mV |
| Type of Product | DC-DC Converter |
| Efficiency (%) | 94.5% |
| Isolation Voltage | 500 V DC |
Load Regulation |
20mV |
Type of Product |
DC-DC Converter |
Efficiency (%) |
94.5% |
Isolation Voltage |
500 V DC |
Isolated |
Yes |
Input Voltage Range |
36 to 76 V DC |
Power Rating |
300 W |
Series |
CHS |
Country of Origin |
Japan |
Output Voltage |
10 V DC |
Mounting Type |
Through Hole |
Name of Manufacturer/Packer/Importer |
Cosel |
No. Of Output |
1 |
Length |
58.9 mm |
Width |
12.7 mm |
Package Type |
DIP |
Output Current |
30 Amp |
Manufacturer Part Number |
CHS3004810-B |
Pack of |
1 Pc |
Minimum Temperature |
-40°C |
Product Code |
1872716 |
Maximum Temperature |
+85°C |
Input Voltage Nominal |
48 V DC |
Depth |
23.26 mm |
Standards Met |
C-UL (CSA60950-1), EN60950-1, UL60950-1 |
Output Voltage Adjustment Range |
±110% |
