| Type of Product | Isolated DC-DC Converter |
| Model No | THI 2-2422M |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | TRACO POWER |
Type of Product |
Isolated DC-DC Converter |
Model No |
THI 2-2422M |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
TRACO POWER |
No. Of Output |
2 |
Application |
None |
Nominal Voltage |
24 V DC |
Minimum Temperature |
-25℃ |
Output Voltage (V) |
±12 DC |
Output Current (mA) |
±83 |
Certification |
Yes |
Import Country |
Direct Import from Japan |
Monotaro ID |
48750985 |
RoHS Directive |
Correspondence |
Packaging Type |
DIP 16 |
Specifications |
EN60950-1, UL60950-1, IEC60950-1, CSA C22.2 No. 60950-1-03, EN60601-1, UL60601-1, IEC60601-1, CSA C22.2 No. 601-1. CB, CSA. The derating MTBF of 2.5% per °C above 60 °C is based on MIL-HDBK-217F (25 °C). . Traco 2 W DIP Single/Dual Output Isolated Unregulated DC-DC Converter-THI-2M Series. Industrial/Medical Safety Certified High Insulation Test Voltage, Reinforced Isolation for Working Voltage up to 6 kV (Peak) 300 Vac Built-in Pi Filter short circuit protection UL94V-0 package material 16-pin DIP with industry standard pinout |
Input Voltage Range (V) |
21.6-26.4 DC |
Rated power (W) |
2 |
Insulation Voltage |
4 kV |
Length (mm) |
8.6 |
Mounting |
Through Hole Mount |
Highest Temperature |
71℃ |
