| Application | Industrial Control System |
| Type of Product | Push Wheel Digital Timer |
| Model No | TDPW-48-Z |
| Mounting Type | Panel Mount |
Application |
Industrial Control System |
Type of Product |
Push Wheel Digital Timer |
Model No |
TDPW-48-Z |
Mounting Type |
Panel Mount |
Time Range |
9.99 sec, 99.9 sec, 999 sec, 99.9 min., 999 min., 99.9 hour (Switch Selectable) |
Supply Voltage |
85~270 V AC/DC |
Size |
48x48 mm |
Country of Origin |
India |
Humidity |
95% RH Non Condensing |
Termination |
Screw Type, for 2.5 mm sq. Wire |
Mode |
On Delay, Interval, Counting : Down |
Name of Manufacturer/Packer/Importer |
M/s Anand Syndicats |
Protection Level |
IP20 |
Output Contact |
DPDT (2 C/O) |
Operating Ambient Temperature |
0 to 55°C |
Storage Ambient Temperature |
-5°C to 50°C |
